Kia 3922038020 Sensor Assembly-Water Temperature

You can Select Your Vehicle to check if 3922038020 fits your vehicle.

The engine coolant must be drained partially so that it is below the height of the cylinder head. Don't drain your radiator; if you do, expect some coolant to run out when you pull the ECT sensor off. On 1994 through 1997 models, the ECT sensor is located right behind the distributor. If you want to disconnect the electrical connector, remove this retainer wire by prying it carefully and then slide out the connector. For 1998 and other later four-cylinder models, it is situated on the left side at the end of a cylinder head facing fire wall. If you wish to separate electrical connections carefully pry loose this retainer wire from its position after which you can easily remove it from there. The ECT sensor on 2.7LV6 engines is just below or directly under ignition coil pack. After un-screwing it, dispose of both old washer gasket and sealing pin for ECT sensors. Please always remember that if such a cool thing as an engine control system would be damaged in any way that would affect driving process badly as well. It should be installed as in reverse procedure beginning with replacement of new sealing washer and tightening up of ECT sensor till torque required for it while refilling with cooling medium has been done adequately enough!

If the coolant temperature gauge is inoperative, check the fuses first. If the temperature gauge indicates excessive temperature after running awhile, troubleshoot the issue. If the temperature gauge indicates HOT as soon as the engine is started cold, disconnect the electrical connector at the coolant gauge sending unit and if the gauge reading drops, replace the sending unit. If the gauge fails to respond, the circuit may be open or the temperature gauge may be faulty. To replace the sending unit, drain the coolant, disconnect the electrical connector for the sending unit, using a deep socket or a wrench, remove the sending unit, install the new sending unit, and tighten it securely, connect the electrical connector, refill the cooling system and check for coolant leakage and proper gauge operation.

Simply disconnect the electrical connector from the ECT sensor.

The ECT sensor is located on the coolant housing under the throttle body.

The ECT sensor should be handled with care, as damage to it will affect the operation of the entire fuel injection system.

Disconnect the electrical connector at the coolant gauge sending unit and if the gauge reading drops, replace the sending unit.

Yes, you can reuse the old ECT sensor, but handle it with care to avoid any damage that could affect the operation of the fuel injection system.
