Main Wiring fit your 2019 Kia Sedona

Diagram (1 of 1): Main Wiring (01/01)
2019 Kia Sedona Main Wiring Diagram
Enlarge Diagram
Sort by:
Part Description
Part Code
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
  • Junction Box Assy-I/Panel
    91188 Kia 91951A9010
    91951A9010
    Junction Box Assy-I/Panel
    • Fit Note: DRL - DEDICATED LED TYPE
      LED POSITION LIGHT GUIDE
      LED POSITION TYPE
      LIGHTING SOURCE - BULB
      LIGHTING SOURCE - LED(LIGHT EMITTING DIODE)
      LOW BEAM - HALOGEN BULB
      POWER SEAT (I.M.S)
      RR - CONVENTIONAL
      RR COMBI LAMP - LED(W/BULB T/SIGNAL)TYPE
    • Production Date: 01/2018-07/2020
    $671.15 $457.05
    1
    Add To Cart
  • 91188
    91951A9160
    Junction Box Assy-I/Panel
    • Fit Note: DRL - DEDICATED LED TYPE
      LED POSITION LIGHT GUIDE
      LIGHTING SOURCE - LED(LIGHT EMITTING DIODE)
      LOW BEAM - HALOGEN BULB
      POWER SEAT (I.M.S)
      RR - CONVENTIONAL
      RR COMBI LAMP - LED(W/BULB T/SIGNAL)TYPE
    • Production Date: 01/2018-07/2020
    $636.65 $452.66
    1
    Add To Cart
  • 91188 Kia 91951A9210
    91951A9210
    Junction Box Assy-I/Panel
    • Fit Note: DRL - DEDICATED LED TYPE
      LED POSITION TYPE
      LIGHTING SOURCE - LED(LIGHT EMITTING DIODE)
      LOW BEAM - LED
      POWER SEAT (I.M.S)
      RR - CONVENTIONAL
      RR COMBI LAMP - LED(W/BULB T/SIGNAL)TYPE
    • Production Date: 01/2018-07/2020
    $671.15 $457.05
    1
    Add To Cart
  • 91188
    91951A9240
    Junction Box Assy-I/Panel
    • Fit Note: DRL - DEDICATED LED TYPE
      LED POSITION LIGHT GUIDE
      LIGHTING SOURCE - BULB
      LOW BEAM - HALOGEN BULB
      POWER SEAT (I.M.S)
      RR - CONVENTIONAL
      RR COMBI LAMP - LED(W/BULB T/SIGNAL)TYPE
    • Production Date: 01/2018-07/2020
    $624.17 $443.78
    1
    Add To Cart
  • 91188 Kia 91951A9290
    91951A9290
    Junction Box Assy-I/Panel
    • Fit Note: DRL - DEDICATED LED TYPE
      LED POSITION TYPE
      LIGHTING SOURCE - BULB
      LOW BEAM - LED
      POWER SEAT (I.M.S)
      RR - CONVENTIONAL
      RR COMBI LAMP - LED(W/BULB T/SIGNAL)TYPE
    • Production Date: 01/2018-07/2020
    $643.44 $447.06
    1
    Add To Cart
  • 91188
    91951A9650
    Junction Box Assy-I/Panel
    • Fit Note: DRL - DEDICATED LED TYPE
      LED POSITION LIGHT GUIDE
      LED POSITION TYPE
      LIGHTING SOURCE - BULB
      LOW BEAM - HALOGEN BULB
      POWER SEAT (I.M.S)
      RR - CONVENTIONAL
      RR COMBI LAMP - LED(W/BULB T/SIGNAL)TYPE
    • Production Date: 01/2018-07/2020
    $620.72 $441.33
    1
    Add To Cart
  • Wiring Assy-Main
    91100 Kia 91189A9050
    91189A9050
    Wiring Assy-Main
    • Fit Note: AROUND VIEW MONITOR SYSTEM - A TYPE
      AUDIO DISPLAY (RADIO+MEDIA) - 7 INT LCD
      AUTO DEFOG SYSTEM
      AUTONOMOUS EMERGENCY BRAKING - CITY
      AVN STD
      BACK WARN'G CAMERA
      FR COOLER - DUAL FULL AUTO A/CON
      IMMOBILIZER
      INVERTER - 115V INVERTER
      INVERTER - 115V INVERTER (2EA)
      LIGHTING FUNCTION - DYNAMIC BENDING LIGHT
      PARK'G ASSIST SYSTEM
      SMART KEY-FR DR
      SPEAKER BRAND - HARMAN/KARDON
      W/ ILLUM
      WIRELESS CHARGING (FR)
    • Production Date: 01/2018-07/2020
